Product Overview
Summit RE203W 20" Electric Coil Range, 4 Burners, 2.3 cu.ft. Oven, Waist-High Broiler, White
The Summit RE203W is a fully featured 20" wide electric coil range designed for apartments and smaller kitchens that need full cooking capability in a slim footprint. Built in North America and designed for 220V operation, it includes four coil elements with removable chrome drip pans, upfront push-to-turn controls, and a 2.3 cu.ft. porcelain oven with a convenient waist-high broiler inside the oven. Safety-focused features and an ADA-friendly control layout make it a practical, space-saving choice.
Key Features ▼
- Slim 20" wide design ideal for apartments and compact kitchens
- 4 coil elements (1 x 8" + 3 x 6") with removable chrome drip pans for easier cleanup
- Waist-high broiler inside the oven for more convenient broiling
- Enhanced safety coil sensors that cycle off near flashpoint temperatures and resume automatically
- Upfront push-to-turn controls + ADA-compliant design for safer, more accessible operation
Specifications ▼
- Brand: Summit
- Model: RE203W
- UPC: 761101058283
- Previous Model: RE201W (replaced by RE203W)
- Product Type: Electric coil top range
- Finish/Color: White
- Door: White
- Cabinet: White (steel, textured cabinet)
- Nominal Height: 42.0" (107 cm)
- Height of Cabinet: 41.75" (106 cm)
- Nominal Width: 20.0" (51 cm)
- Width: 19.5" (50 cm)
- Nominal Depth: 26.0" (66 cm)
- Depth: 25.13" (64 cm)
- Depth with Handle: 27.38" (70 cm)
- Depth with Door at 90°: 46.38" (118 cm)
- US Electrical Safety: UL
- Voltage/Frequency: 220 V AC / 60 Hz
- Power Source: 220V
- Cord Included: No (compatible with standard 40 amp 3- or 4-wire range cords)
- Weight: 125.0 lbs. (57 kg)
- Parts & Labor Warranty: 1 Year
- Oven Capacity: 2.3 cu.ft. (65 L)
- Cleaning Type: Manual
- Oven Rack Quantity: 2
- Broiler Location: Inside Oven (waist-high broiler)
- Oven Interior Height: 15.25" (39 cm)
- Oven Interior Width: 14.5" (37 cm)
- Oven Interior Depth: 17.63" (45 cm)
- Cooktop Surface: Metal
- Element Type: Coils
- Number of Elements: 4
- Element Configuration: One 8" element + three 6" elements
- Element #1: 6.0" (15 cm), 1250W
- Element #2: 6.0" (15 cm), 1250W
- Element #3: 6.0" (15 cm), 1250W
- Element #4: 8.0" (20 cm), 2400W
- Burner Controls: Dial (upfront)
- Oven Controls: Dial
- Backguard/Backsplash: Yes
- Indicator Lights: Yes (oven and burners)
- Knob Safety: Push-to-turn knobs
- Oven Rack Safety: Safety brake system for racks
- Drip Pans: Removable chrome drip pans
- Safety Elements: Sensor cycles element off near flashpoint temperature and resumes heating automatically
- ADA Compliant Design: Yes (upfront controls, easy-to-operate knobs)
- TAA Compliant: Yes (made in North America; meets TAA guidelines)
