Product Overview
AIMS Power 3000 Watt Low Frequency Inverter Pure Sine Inverter Charger; Listed to UL 458 Standards
AIMS Power 3000 Watt Pure Sine Low Frequency Inverter with built-in battery charger and transfer switch; This inverter charger is perfect for small-sized industrial applications that depend upon power being available even under heavy load. This heavy-duty inverter charger is ready to go wherever you need it. Use this product for renewable solar, off-grid home and business back up power, mobile and emergency backup power applications anywhere that uses 110 or 120 volts of alternating current. This product also has auto frequency detection that allows users to operate at either 50 or 60 hertz.Use this product to power your essential household appliances during a power outage emergency.
Key Features:
- Listed to UL 458 Standards and CSA 22.2 No 107.1
- 3000 watt low frequency inverter
- 9000 watt surge for 20 seconds -3x surge capability
- Battery priority selector
- AC direct connect terminal block
- GFCI - 20 amps
- Marine coated and protected
- Multi stage smart charger 100 Amp GEL, AGM, Lead and lithium LiFePO4
- Remote panel available
- Auto gen start
- Auto frequency
- 10msec typical transfer time
- 7 battery type settings for charger
- Selectable 25W power save mode (hibernation)
- Automatic transfer switch
Specifications:
| Inverter Output | |
| Continuous Output Power | 3000 Watts |
| Surge Rating | 9000 Watts (20 Seconds) |
| Output Waveform | Pure Sine/Same as input (Bypass Mode) |
| Output Voltage | 100-110-120Vac |
| Nominal Efficiency | >92% (Peak) |
| Line Mode Efficiency | >95% |
| Output Frequency | 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz |
| Bypass Terminal Breaker | 40 amps |
| Typical Transfer Time | 10ms (Max) |
| THD | < 10% DC |
| Ambient Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Input Specifications: | |
| Nominal Input Voltage | 12.0Vdc |
| Minimum Start Voltage | 10.0Vdc |
| Low Battery Alarm | 10.5Vdc-11.0Vdc |
| Low Battery Trip | 10.0Vdc-10.5Vdc |
| High Voltage Alarm | 16.0Vdc |
| Charger Specifications: | |
| Output voltage | Depends on battery Type |
| Charger Rate | 100A |
| Dimensions: | |
| Shipping L x W x H | 20.5 X 13.8 X 12.2 inches |
| Shipping Weight | 66 lbs. |
