Product Overview
Seco-Larm SD-H412 Electric Transfer Hinge – 12/24VAC/VDC, 4-Wire, Vandal-Resistant
The SD-H412 Electric Transfer Hinge is a heavy-duty solution designed to deliver reliable power and data transfer between door frames and doors without exposed wiring. Built with a vandal-resistant steel housing, it replaces a standard hinge on hollow doors and supports both 12V and 24V AC/DC operation, making it ideal for access control and security installations.
Key Features ▼
- Supports 12 or 24 VAC/VDC operation for flexible installations
- 4 conductive 28AWG wires for secure power and data transfer
- Heavy-duty, vandal-resistant steel housing protects internal wiring
- Standard 5-knuckle hinge design replaces existing door hinge
- Designed for hollow doors to maintain clean, concealed wiring paths
Specifications ▼
- Manufacturer: Seco-Larm
- Model: SD-H412
- Product Type: Electric Transfer Hinge
- Operation Voltage: 12 or 24 VAC/VDC
- Current Rating: 0.5A at 24VAC/VDC
- Wire Type: 4 Conductive Wires
- Wire Gauge: 28AWG
- Hinge Type: Standard 5-Knuckle
- Application: Hollow Doors
- Function: Power and Data Transfer
- Finish: US26D (652)
- Construction: Steel, Vandal-Resistant Housing
- Dimensions: 4.50 x 4.50 x 0.12 inches
- Product Weight: 1 lb
Warranty Information
Warranty is covered by the manufacturer
