Product Overview
Opticis DPFX-700-TR DisplayPort 1.2 Extender, 4K@60Hz, 200m Optical Range
The Opticis DPFX-700-TR is a professional-grade DisplayPort 1.2 fiber-optic extender, delivering ultra-high-definition 4K@60Hz video over distances of up to 200 meters. Its robust design ensures uncompressed, transparent signal transmission ideal for applications in medical imaging, military environments, digital signage, and more.
Key Features â–¼
- 4K@60Hz Transmission: Supports UHD video resolutions with RGB and YCbCr 4:4:4 color formats.
- Extended Range: Reliable signal transmission over 200 meters using LC multi-mode fiber.
- High Data Rate: Achieves up to 21.6 Gbps data rate (5.4 Gbps per lane).
- Plug-and-Play: Easy installation with auto power switching and no additional drivers required.
- Dual Compatibility: Supports MST, auxiliary channels, and DP++ standards for versatile applications.
Specifications â–¼
- DisplayPort Standard: 1.2
- Resolution: Up to 4K (4096x2160) @ 60Hz, 4:4:4 color
- Transmission Distance: Up to 200 meters over LC multi-mode fiber (OM3)
- Data Rate: 21.6 Gbps total (5.4 Gbps per lane)
- Compatibility: Dual-mode DP (DP++), MST, auxiliary/I²C channels
- Power Supply: Auto power switching
- Certifications: FCC, CE
- EMI/RFI Shielding: Yes
- Design: Compact, lightweight, detachable
Warranty Information
Warranty is covered by the manufacturer
