Product Overview
Elmo MX-P3 Document Camera – 13 MP 4K UHD, 16× Digital Zoom, Built-in Mic, HDMI/RGB/USB & SD
The Elmo MX-P3 (Model 1450) is a sleek, ultra-portable document camera that delivers True 4K resolution at 30 fps or Full HD at 60 fps. Its flexible arm, magnetic base, and foldable design make it ideal for educators, professionals, and creators who need crystal-clear imaging on the go. Equipped with a built-in microphone, SD card slot, and multiple connectivity options—HDMI, RGB/VGA, and USB-C—it’s a plug-and-play powerhouse for presentations, remote teaching, and video conferencing.
Key Features ▼
- 16× Digital Zoom at True 4K: Zoom into fine details without loss in image quality.
- Multi-Output Connectivity: Seamlessly connect via HDMI, RGB/VGA, or USB-C—plus an SD card slot for direct saving
- Built-in Microphone: Perfect for recording or live conferencing without extra gear.
- Compact, Flexible Design: Folds down to smartphone-size and features a magnetic base for stable placement.
- Plug-and-Play: UVC-compliant USB connectivity means zero drivers across Windows, macOS, and Chrome OS.
Specifications ▼
- Manufacturer Part Number: 1450
- Model: MX-P3
- Country of Origin: Thailand
- Sensor: 13 Megapixel CMOS (approx. 1/3.1")
- Effective Pixels: 4160 (H) × 3120 (V) (4:3)
- Lens Aperture: F=2.0
- Frame Rates: 30 fps at 4K / 60 fps at 1080p
- Digital Zoom: 16×
- Focus: Auto (one-push)
- Imaging Area: 14.7″ × 11.1″ (4:3)
- Brightness Adjustment: 7 levels (Default: 8)
- Image Rotation: 0° / 180°
- Illumination: White LED
- Connectivity: USB-C (USB-UVC), HDMI Type-A, RGB/VGA (Mini D-Sub 15), SD Card slot
- Outputs: Simultaneous USB, HDMI, RGB
- Built-in Microphone: Yes (USB); ON/OFF switch
- Power Source: DC 5 V via USB-C or jack
- Power Consumption: ~4 W (USB), ~6 W (HDMI/RGB)
- Dimensions (Setup): 13.5″ W × 3.2″ D × 11.9″ H
- Dimensions (Folded): 11.4″ W × 3.2″ D × 0.9″ H
- Weight: ~1.0 lb / 460 g
- Shipping Weight: ~1.15 lb
- Shipping Dimensions: 17″ L × 13″ W × 5″ H
