Product Overview
Allen & Heath QU-24C 30 In/24 Out Compact Digital Mixer, Chrome Edition
Allen & Heath AH-QU-24C Model Qu-24C Rack Mountable Reshapes Digital Mixer, Chrome Edition, 24 Mono Mic/Line Inputs (TRS + XLR), 3 Stereo Inputs (TRS), 20 Mix Outputs (XLR)
Now in a feature-packed new Chrome Edition, Qu-24 reshapes digital mixing, combining innovative design and exceptional functionality to create a superb professional mixing experience. Bristling with all the features you’d expect from a top of the range digital console and incorporating technologies pioneered on the GLD and iLive digital mixing systems.
Key Features
- 24 Mono Mic/Line Inputs (TRS + XLR)
- Recallable AnaLOGIQ Preamps
- 3 Stereo Inputs (TRS)
- 20 Mix Outputs (XLR)
- 2 Stereo Groups (switchable to Mix mode)
- Up to 9 Monitor Mixes (4 mono + 5 stereo)
- 2 Stereo Matrix Outs
- 4 FX Engines
- 4 dedicated FX Sends/Returns
- 4 Mute Groups
- 4 DCA Groups
- AES Digital Out
- 32x30 USB Audio Interface
- dSNAKE Remote Audio Port
- 25 Motor Faders
- 800x480 Touchscreen
- 10 Soft Keys
- Trim, polarity, HPF, gate, insert, 4-band PEQ, compressor, delay on all Inputs
- Insert, 4-band PEQ, 1/3 octave GEQ, compressor, delay on all Outputs
- Automatic Mic Mixer
- Channel Ducker on all inputs
- ProFactory Mic Presets
- RackFX Library
- Built-in Signal Generator
- RTA with Peak Band indication
- Spectrogram to aid feedback elimination and room acoustics
- Qu-Drive Direct Multitrack Recording/Playback on USB drives
- DAW MIDI Control
- Qu-Pad iPad App
- Qu-You iPhone/Android personal monitoring app
- Qu-Control customisable iOS app for simple wireless control
- Fits with ME Personal Mixing System
- High contrast metallic finish controls
- Dimensions 30.75"x26.5"x13.75"
- Weight 43.4 Lbs
