Product Overview
ZLINE RAZ-36-G 36" Autograph Dual Fuel Range, 6 Italian Burners, Electric Convection Oven, Gold Accents
The ZLINE Autograph Edition RAZ-36-G combines the responsiveness of a 6-burner gas cooktop with the precision of an electric convection oven to deliver a professional dual-fuel cooking experience. Built with 304-grade stainless steel, a porcelain cooktop for easier cleanup, and elevated polished gold knobs and handle, this 36" Legacy Series range brings performance, style, and everyday versatility to your kitchen—backed by a limited lifetime warranty on ZLINE Italian burners.
Key Features ▼
- Professional dual fuel performance: gas cooktop + electric convection oven for even heat distribution
- 6 Italian-made sealed burners with 1,000–18,000 BTUs of cooking power
- 4.6 cu. ft. oven capacity designed to fit pans up to 27 inches wide
- Autograph Edition polished gold accents (knobs and handle) for a premium look
- Premium insulation & visibility: triple-layer glass window, aluminum mesh seal, and dual halogen oven lights
Specifications ▼
- Brand: ZLINE
- Series: Legacy Series (Autograph Edition)
- Manufacturer Part Number (MPN): RAZ-36-G
- Model: RAZ-36-G
- UPC: 810058127402
- Appliance Category: Freestanding Range
- Range Size (Width): 36 in.
- Fuel Type: Gas Cooktop + Convection Electric Oven (Dual Fuel)
- Color / Finish Family: Stainless Steel
- Hardware Color/Finish: Polished Gold
- Overall Dimensions (W x D x H): 35.75 in. W x 27.5 in. D x 36.125 in. H
- Product Width: 35.75 in.
- Product Depth: 27.50 in.
- Product Height: 36.13 in.
- Depth with Door Open 90°: 41.8 in.
- Adjustable Legs: Yes (adjust total height from 36 in. to 38.5 in.)
- Oven Capacity: 4.6 cu. ft.
- Oven Features: Manual Clean; Convection Electric; 4.6 cu. ft. deep oven; Triple Glass Window; Dual Lighting; Professional Aluminum Mesh Seal
- Convection Fan: Yes
- Oven Interior Dimensions (W x D x H): 24.875 in. W x 17.75 in. D x 16 in. H
- Oven Window: Landscape oven door window design
- Oven Lights: Dual halogen lighting (front control panel switch)
- Oven Racks: 2 smooth-glide ball-bearing oven racks
- Oven Door Hinges: StayPut oven door hinges
- Cooktop: Porcelain cooktop
- Cooktop Features: (6) burners with porcelain cooktop and electronic spark ignition for all burners
- Burner Type: Italian-made sealed burners (hand-cast)
- Burner Power Range: 1,000 to 18,000 BTUs
- Total BTUs: 67,500
- Front Left Burner BTU: 18,000
- Front Right Burner BTU: 12,500
- Back Left Burner BTU: 12,500
- Back Right Burner BTU: 4,500
- Control Type: Manual front control
- Electrical Requirements: Dedicated 240V, 60Hz, 15-amp circuit; NEMA 14-50 4-wire plug system
- Voltage: 240vac
- Frequency: 60Hz
- Amps: 15A
- Certifications and Listings: CSA Listed
- Product Weight: 253 lb
- LP Conversion Kit: Included (conversion must be done by a professional)
- Cleaning: Minimal cleaning; hand-finished porcelain one-piece cooktop
- Assembly: Ships in multiple boxes; minimal assembly required
- Warranty: 1-year parts and service; limited lifetime warranty on burners
- Lifetime Burner Warranty: Limited lifetime warranty on ZLINE Italian burners (burners & burner caps parts replacement; parts & labor for spark tips if defective)
Warranty Information
1-year parts and service; limited lifetime warranty on burners
