Product Overview
Summit HC24WW 24" Convertible Under-Cabinet Range Hood, 270 CFM, White, Ducted/Ductless
The Summit HC24WW is a compact, low-profile 24-inch under-cabinet range hood designed for smaller kitchens, apartments, and space-conscious installs. Its convertible venting supports either ducted exhaust (top or rear) or ductless/recirculating operation, while a 2-speed fan up to 270 CFM helps clear smoke, grease, and cooking odors. Built from durable 21-gauge galvanized steel with a clean white matte finish, it delivers dependable ventilation in a classic, easy-to-match design.
Key Features â–Ľ
- Convertible venting flexibility: Ships preset for ductless/recirculating, converts easily to ducted ventilation
- Strong 270 CFM performance: Helps ventilate typical 24" cooking surfaces effectively
- Durable steel construction: 21-gauge galvanized steel with powder-coated finish (heavier gauge than many under-cabinet hoods)
- Angled airflow design: Upward-angled vents help keep smoke/odors from blowing toward the cook
- Includes combo charcoal/aluminum mesh filter: Helps absorb grease, smoke, and odors; snap-in removable design for fast replacement
Specifications â–Ľ
- Brand: Summit
- Model: HC24WW
- Product Type: Under-cabinet range hood
- Installation: Under Cabinet
- Venting: Convertible (ducted or ductless/recirculating)
- Nominal Width: 24.0" (61 cm)
- Actual Width: 23.88" (61 cm)
- Nominal Depth: 20.0" (51 cm)
- Actual Depth: 20.0" (51 cm)
- Nominal Height: 6.0" (15 cm)
- Height of Cabinet: 5.5" (14 cm)
- Finish / Cabinet Color: White (matte)
- Construction: 21-gauge galvanized steel with powder-coated finish
- Controls: Dial
- Control Type (additional): Rocker switch controls (front-located on/off and high/low switches for light and fan)
- Number of Fan Speeds: 2
- Maximum Air Movement: 270 CFM
- Sone Rating: 6
- Airflow Design: Angled upward airflow
- Duct / Vent Options: Top or rear exhaust
- Duct Shape: 3 1/4" x 10" rectangular OR 6/7" round with transition
- Compatible Ducting: 3 1/4" x 10" vertical or horizontal exterior venting; 7" round vertical (transition required)
- Filter Type: Combination charcoal/aluminum mesh filter
- Filter Design: Snap-in removable filter
- Lighting: Accepts a standard incandescent bulb (bulb not included)
- Lens Cover: Snap-in (tool-free removal)
- Electrical Safety: UL (US), ULC (Canada)
- Electrical: 115 V AC / 60 Hz
- Amps: 1.7
- Power Cord: Not included
- Installation Requirement: Designed to be hard-wired by a licensed professional
- Compliance: TAA compliant
- Net Weight: 12.0 lbs (5 kg)
- Warranty: 1 Year Parts & Labor
- UPC: 761101087092
