Product Overview
Summit CR2B224S 230V 2-Burner Coil Electric Cooktop, Stainless Steel, Portrait/Landscape Install
The Summit CR2B224S is a compact 230V electric cooktop built for flexible installation in either portrait or landscape orientation, making it a smart fit for tight kitchens, hospitality setups, and custom countertop layouts. It features a durable stainless steel surface, two coil elements for fast everyday cooking, and safety-focused push-to-turn controls with indicator lights for clear operation.
Key Features ▼
- Portrait or landscape installation: Controls and burners are designed to be easy to read and use in either direction
- Fits common 20" x 16" cutouts: Built-in design sized for popular countertop cutout requirements
- Two coil heating elements: Includes one 1800W and one 1200W burner for versatile cooking
- Push-to-turn controls + indicator lights: Added safety and clear “burner in use” visibility
- Stainless steel finish: Attractive, easy-to-clean surface suited for residential or hotel kitchens
Specifications ▼
- Brand: Summit
- Model: CR2B224S
- Product Type: Electric Cooktop
- Installation: Built-in; portrait or landscape mounting
- Heating Type: Radiant
- Element Type: Coils
- Number of Elements: 2
- Element #1 Size: 5.5" (14 cm)
- Element #1 Wattage: 1200 W
- Element #2 Size: 7.0" (18 cm)
- Element #2 Wattage: 1800 W
- Controls: Dial
- Control Type: Push-to-turn
- Indicator Lights: Yes (shows which burner is in use)
- ADA Compliant Design: Yes (upfront controls and easy-to-operate knobs)
- Surface Material: Stainless Steel
- Cabinet Material: Stainless Steel
- Nominal Width: 22.0" (56 cm)
- Actual Width: 21.25" (54 cm)
- Nominal Depth: 18.0" (46 cm)
- Actual Depth: 18.0" (46 cm)
- Nominal Height: 3.38" (9 cm)
- Height of Cabinet: 3.38" (9 cm)
- Countertop Cutout Height: 3.0" (8 cm)
- Countertop Cutout Width: 20.0" (51 cm)
- Countertop Cutout Depth: 16.0" (41 cm)
- Electrical Safety (US): ETL
- Electrical Safety (Canada): ETL-C
- Voltage/Frequency: 230 V AC / 60 Hz
- Amps: 20.0 A
- Power Cord Included: No
- Installation Requirement: Professional installation required
- Parts & Labor Warranty: 1 Year
- UPC: 761101050454
