Product Overview

Summit BIM27OSADA 15" ADA Compliant Built-In Outdoor Manual Defrost Icemaker, Stainless Steel

The Summit BIM27OSADA is a compact, built-in undercounter icemaker designed for outdoor or indoor use with a complete stainless steel exterior. Sized at just under 15" wide, it fits perfectly under ADA-compliant counters and features a manual defrost system that keeps ice solid longer. This weatherproof, drain-free icemaker produces up to 25 lbs of crescent-shaped ice daily and stores 22 lbs, making it ideal for outdoor kitchens, wet bars, or any space where reliable ice supply is essential.

Key Features ▼

ADA Compliant Design: 31.75" height fits under lower ADA-compliant counters; adjustable height up to 34" with included kickplate.
Drain-Free Operation: No drain or pump required, allowing flexible installation indoors or outdoors.
Durable Stainless Steel Exterior: 304-grade stainless steel cabinet and door for weatherproof, professional-grade finish.
Manual Defrost Cooling: Static cooling system preserves ice quality longer than other systems.
Large Ice Production & Storage: Produces 25 lbs of crescent-shaped ice daily with 22 lbs storage capacity; includes removable bin and ice scoop.

Specifications ▼

Brand: Summit
Model: BIM27OSADA
UPC: 761101103549
Product Type: Built-In Undercounter Icemaker
ADA Compliant: Yes
Installation: Built-In or Freestanding
Nominal Height: 32.0" (81 cm)
Height of Cabinet: 31.75" (81 cm)
Nominal Width: 15.0" (38 cm)
Width: 14.88" (38 cm)
Nominal Depth: 20.0" (51 cm)
Depth: 19.38" (49 cm)
Depth with Handle: 21.38" (54 cm)
Depth with Door at 90°: 33.63" (85 cm)
Defrost Type: Manual
Door: Stainless Steel, RHD (Right-Hand Door Swing) or LHD (Left Hand Door Swing)
Cabinet: Stainless Steel (304-grade)
Electrical Safety (US): ETL
Electrical Safety (Canada): ETL-C
Amps: 1.9
Voltage/Frequency: 115 V AC / 60 Hz
Weight: 61.0 lbs (28 kg)
Daily Ice Production: 25.0 lbs (11 kg)
Ice Storage Capacity: 22.0 lbs (10 kg)
Ice Shape: Crescent
Ice Cube Size: 1/2" x 3/4" x 2 3/8"
Number of Ice Cube Sizes: 1
Refrigerant Type: R600a
Refrigerant Amount: 1.58 oz
High Side PSI: 120.0
Low Side PSI: 55.0
Interior Dimensions (H x W x D): 15.88" x 11.88" x 12.38" (40 x 30 x 31 cm)
Leveling Legs: 4
Features: Reversible door, adjustable height, sealed back, weatherproof design, standard water hookup (1/4" OD water supply line)
Included Accessories: Water filter (optional use), ice scoop and holder
Warranty: 1 Year Parts & Labor, 5 Year Compressor Warranty
Compliance: Lead-free certified, NSF/ANSI/CAN 61-2022, NSF/ANSI/CAN 372-2022, California Health and Safety Code 116876
