Product Overview

Summit BIM271OS 15" Outdoor Built-In No-Drain Icemaker, 25 lb/day, 304 Stainless, Manual Defrost

The Summit BIM271OS is a premium built-in undercounter icemaker designed for indoor or outdoor use, featuring a complete 304-grade stainless steel wrapped exterior and a no-drain-required design for easier placement. It produces up to 25 lbs of crescent ice per day and stores 22 lbs, while a static manual defrost cooling system helps keep ice frozen longer. With a front-breathing design for built-in installation, a fully finished cabinet for freestanding use, and an ADA-capable adjustable height option, it’s a luxury convenience upgrade for outdoor kitchens, wet bars, and entertaining spaces.

Key Features ▼

No drain required: Drain-free design adds flexibility for installation indoors or outside without needing a floor drain or pump.
Indoor/outdoor, weatherproof build: Durable construction and 304 stainless steel exterior suitable for outdoor kitchens.
High capacity output & storage: Produces 25 lbs/day and stores 22 lbs of crescent-shaped ice.
ADA-capable adjustable height: Can be lowered to just under 32"; includes a smaller kickplate for a seamless look.
Manual defrost static cooling: Designed to keep ice frozen longer compared to other systems; includes removable bin, scoop, and holder.

Specifications ▼

Brand: Summit
Model: BIM271OS
UPC: 761101103556
Product Type: Built-In Undercounter Icemaker
Installation: Built-In capable (front-breathing); also suitable for freestanding use
Use: Indoor/Outdoor capable
Weatherproof Design: Yes
Defrost Type: Manual
Cooling System: Static cooling system
Drain Required: No
Pump Required: No
Daily Ice Production: 25.0 lbs (11 kg)
Ice Storage Capacity: 22.0 lbs (10 kg)
Ice Shape: Crescent
Number of Ice Cube Sizes: 1
Ice Cube Size: 1/2" x 3/4" x 2 3/8"
Nominal Height: 34.0" (86 cm)
Height of Cabinet: 34.0" (86 cm)
Nominal Width: 15.0" (38 cm)
Width: 14.88" (38 cm)
Nominal Depth: 20.0" (51 cm)
Depth: 19.38" (49 cm)
Depth with Handle: 21.38" (54 cm)
Depth with Door at 90°: 33.63" (85 cm)
Interior Height: 15.88" (40 cm)
Interior Width: 11.88" (30 cm)
Interior Depth: 12.38" (31 cm)
Door Finish: Stainless Steel
Cabinet Finish: Stainless Steel
Exterior Material Grade: 304-grade stainless steel wrapped exterior finish
Handle: Horizontal towel bar style handle (stainless steel)
Back: Sealed back
Door Swing: RHD (Right Hand Door Swing) or LHD (Left Hand Door Swing)
Reversible Door: Yes
Height Adjustable: Yes (can be lowered just under 32" with included smaller kickplate for ADA spaces)
Level Legs: 4
Water Hookup: Standard 1/4" OD water supply line
Connection Hose: Pre-installed connection hose
Filter: Water filter included (optional use; mounts in rear)
Included Accessories: Removable ice bucket (bin), ice scoop, scoop holder, optional water filter
Storage Bin: Insulated storage bin
Refrigerant Type: R600a
Refrigerant Amount: 1.58 oz
High Side PSI: 120.0
Low Side PSI: 55.0
Electrical Safety (US): ETL
Electrical Safety (Canada): ETL-C
Amps: 1.9
Voltage/Frequency: 115 V AC / 60 Hz
Product Weight: 61.0 lbs (28 kg)
Environmental: 100% CFC free
Lead-Free Certified: Complies with CA Health & Safety Code 116876 lead leaching requirements per NSF NSF/ANSI/CAN 61-2022, and lead content requirements per NSF/ANSI/CAN 372-2022 and U.S. Safe Drinking Water Act Section 1417(d)
Warranty (Parts & Labor): 1 Year
Compressor Warranty: 5 Years
