Seco-Larm SD-72231-6MQ Mortise Cylinder Key Switch with LEDs Maintained Output
The ENFORCER Single-Gang Mortise Cylinder Key Switch with LEDs (Maintained) is a reliable backup solution for electronic locking systems.
If the primary access control device fails, this switch allows authorized personnel to manually override the system and unlock the door. It features a maintained switching mechanism, meaning the contacts remain in the selected state (N.O. or N.C.) until manually switched back. The keyed mortise cylinder provides added security, while the LEDs clearly indicate the switch's current status. Designed for single-gang installation, its compact and durable construction makes it a valuable addition to any access control system.
Key Features
- Keyed mortise cylinder (2 keys included)
- Mortise cylinder removable for ease of keying
- Red (standby) and green (triggered) LEDs
- Flush mount with vandal-resistant security screws
- Chrome-plated aluminum back plate fits to single-gang back box
- Stainless steel front cover conceals mounting screws
- DPDT, 25A@24VAC contact rating
- Color-coded wires for easy wiring
- Maintained output
Specifications
| Output | Maintained |
| Switch type | DPDT Switch |
| LED Indicators | Red (standby) and green (triggered) |
| Contact switch | 25A@24VAC, NO/NC |
| Dimensions | 2-3/4″x4-1/2″x1-7/16″ (69x114x37 mm) |
