Product Overview
Summit HC20SS 20" Convertible Under-Cabinet Range Hood, 270 CFM Stainless Steel
The Summit HC20SS is a compact 20-inch under-cabinet range hood engineered to support ADA guideline compliance with a design that can be wired to run from a wall switch for improved accessibility. It delivers up to 270 CFM of ventilation with two fan speeds, ships preset for ductless/recirculating use, and converts easily to ducted venting when exterior ventilation is available. A real stainless steel finish and durable heavy-gauge construction provide a clean, professional look built for long-term use in smaller kitchens.
Key Features â–Ľ
- ADA-compliant design available: Wired to run off a wall switch; includes remote terminal block and wall switch cover for accessible control placement
- Convertible venting: Ships preset for ductless (recirculating) and converts for ducted top or rear exhaust
- Powerful 270 CFM airflow: Two-speed fan (high/low) for effective smoke and odor removal
- Angled airflow vents: Directs smoke and odors upward to help prevent blowback toward the cook
- Durable stainless construction: 21-gauge galvanized steel body; stainless exterior with horizontal grain and snap-in filter/lens for tool-free service
Specifications â–Ľ
- Brand: Summit
- Model: HC20SS/HC20SSADA
- Product Type: Under-Cabinet Range Hood
- ADA Compliance option available: Designed for installation compliant with ADA Guidelines (Sections 308 and 309)
- Nominal Width: 20.0" (51 cm)
- Width: 20.0" (51 cm)
- Nominal Depth: 20.0" (51 cm)
- Depth: 20.0" (51 cm)
- Nominal Height: 6.0" (15 cm)
- Height of Cabinet: 5.5" (14 cm)
- Finish: Stainless steel (horizontal grain)
- Cabinet Material: Stainless Steel
- Construction: 21 gauge steel construction (53% heavier gauge than most under-cabinet hoods)
- Installation: Under Cabinet
- Venting: Convertible (ducted or ductless/recirculating)
- Default Venting Mode: Ships pre-set for recirculating (ductless) mode
- Maximum Air Movement: 270 CFM
- Number of Fan Speeds: 2
- Sone Rating: 6
- Duct Shape Options: 3 1/4" x 10" rectangular or 7" round
- Exhaust Configuration: Top or rear exhaust (vertical or horizontal); 7" round vertical (transition required)
- Controls: Dial
- Control Accessibility Feature: Wired to run off a wall switch; remote terminal block included
- Switch Type: Rocker switch controls (front-located on/off and high/low switches)
- Filter Type: Combination charcoal/aluminum mesh filter
- Filter Design: Removable snap-in filter for easy replacement
- Lighting: Accepts a standard incandescent bulb (bulb not included)
- Lens Cover: Snap-in (no tools required)
- Electrical: 115 V AC / 60 Hz
- Amps: 1.7
- Power Cord: Not included
- Installation Requirement: Designed to be hard-wired by a licensed professional
- US Electrical Safety: ETL
- Canadian Electrical Safety: ETL-C
- Weight: 11.0 lbs (5 kg)
- Warranty: 1 Year Parts & Labor
- TAA Compliant: Yes
- Recommended Cooking Surface Size: Sized for use over 20" cooking surfaces
