Product Overview
Seco-Larm SK-1011-SDQ Enforcer Access Control Keypad – 1000 User Codes, Real-Time Clock, Output Relay
The Seco-Larm SK-1011-SDQ Enforcer Access Control Keypad is designed for indoor use in access control systems. This keypad offers a high level of security with up to 1000 user codes and the ability to store 50 visitor codes. It includes a real-time clock, customizable output modes, and multiple activation sounds. The keypad also features 1 master code and 1 super user code for secure management. It is easy to install and compatible with 12-24 VAC/VDC power sources, making it ideal for various commercial and industrial applications.
Key Features ▼
- Up to 1000 User Codes: Can store up to 1000 user codes, with 4-8 digits for secure access control.
- Real-Time Clock: Includes a built-in real-time clock for time-based access management.
- Multiple Output Modes: Adjustable output relay activation times, with a toggle option for up to 99,999 seconds.
- Egress Output: Egress input with various features for flexible access control.
- Weatherproof and Durable: Suitable for indoor use with an operating temperature range of -4°F to 158°F.
Specifications ▼
- Manufacturer Part Number: SK-1011-SDQ
- Model: SK-1011-SDQ
- UPC: 676544015932
- Input Voltage: 12-24 VAC/VDC
- Current Draw at 12VDC: 15mA Standby, 30mA Keypress, 55mA Output 1 Active, 90mA Max Total Current
- Output Type: #1-Form C Output (1A @ 30VDC), Tamper Output 50mA@24VDC
- Codes: 1 Master Code (4-8 digits), 1 Super User Code (4-8 digits), 1000 User Codes (4-8 digits), 50 Visitor Codes (4-8 digits)
- Output Mode: Adjustable, up to 99,999 seconds, with toggle functionality
- Operating Temperature: -4°F to 158°F
- Operating Humidity: 5-95% Non-condensing
- Dimensions: 4 5/8" x 2 7/8" x 1 1/2" (including back box)
- Weight: 6 ounces
- Includes: Back Box, Diode, Manual, 2 Installation Screws, and 2 Mounting Screws
- Special Features: On/Off keypad sounds, Output relay activation sounds (No beeps, 1 second beep, 2 short beeps)
- Lockout Options: Wrong-code system lockup: 60-second lockout, 15-minute lockout, Off
- Code Entry Mode: Auto (no #, same length codes) or Manual (#, variable length codes)
Warranty Information
Warranty is covered by the manufacturer
